Belt Scale Controller [ESS211]
Belt Scale Controller [ESS211]
Belt Scale Controller [ESS211] Belt Scale Controller [ESS211]

Belt Scale Controller [ESS211]

50000.00 INR/Unit

Product Details:

X

Price And Quantity

  • 50000.00 INR/Unit
  • 1 Unit

Trade Information

  • Cash Advance (CA)
  • 7 Days
  • All India

Product Description

Product details : Executing Standard
  • Continuous Totalizing Automatic Weighing Instruments International Recommendation.
  • Accuracy Grade: 0.5.
  • Accuracy of Flow Control: 0.5%~1.0%.
Display
  • 128-64 LCD display screen with 7 background colors for English display.
  • Display Refreshing Time: Setting Range 0.1~2.0s.
Kaypad
  • 16 key English keypad.
  • Menu Shortcut operation with key tone.
Loadcell Interface
  • Excitation Voltage/Max. Current: DC10V/250mA [8 350o loadcells].
  • Signal Input Range: 0~25mV.
  • ADC: 24 bit, 100,000 internal c ode used.
  • Sampling Frequency: 200Hz.
  • Zero Drift: +0.1 V/ RTI (Relative to Input).
  • Gain Drift: 5ppm/5ppm
  • Non linearity: 0.005%FS.
Speed Sensor Interface
  • Output Voltage/Max. Current: DC12V/100mA.
  • Speed Pulse Input Range: 0.5~3000Hz.
  • Speed Pulse: 1024ppr
Switch Signal Interface
  • 3 Normally Open Switch Inputs [DI].
  • 4 Normally Open Relay Switch Outputs [DO]: AC250V/DC24V, 1A.
  • 1 Totalized Weight High speed Pulse Output [PO]: 100mA, DC5~24V; Weight
  • per Pulse and Pulse Width can be preset.
Analog Signal Interface
  • Max.3 Definable Flow/Control Current /Analog Signal Outputs [AO]:
  • 4~20mA, Non linearity: 0.05%FS; AO3 is optional. 1 Optional Flow Setpoint Analog Signal Input [AI]: 4~20mA, Non linearity: 0.05%FS.
Digital Communication Interface
  • COM1: Optional RS232/RS485/RS422/Profibus-DP/Ethernet modules.
  • COM2: RS232.
  • Connectable: IPC/PLC, LED Remote Display, Serial Printer and Wireless Module.
Report Print
  • Weight Records per shift/day/month of a year can be queried and printed.
Operating Specification
  • Operating Voltage: AC220V +15%, 50/60Hz.
  • Max. Power Consumption: 15W.
Outline Size
  • Model Horizontal Panel-mounting: 164-86-193mm [W-H-D].
  • Model Vertical Panel-mounting: 86-164-193 mm [W-H-D].
  • Model Wall-mounting: 202-305-90 mm [W-H-D]
Panel Cut-out Size
  • Model Horizontal Panel-mounting: 153-77mm [W-H].
  • Model Vertical Panel-mounting: 77-153mm [W-H].
  • Operating Temperature: -20 to +40
  • Storage Temperature: -30 to +60
  • Relative Humidity: Max. 85%RH.
Protection Level
  • Front Panel of Model Panel-mounting: IP65.
  • Model Wall-mounting: IP65.
Weight
  • Model Panel-mounting: Approx. 1.7 kg.
  • Model Wall-mounting: Approx. 3.4 kg.



Technical Specification :

Accuracy


Application


Display Type


Loadcell Interface


Loadcell Excitation


AD Conversion


Digital Outputs[DO]


Digital Inputs[DI]


Analog Outputs[AO]


Analog Input[AI]


Speed Sensor


Speed Sensor Supply Voltage:


Speed Pulse Input Range


Pulse Output [PO]


Digital Communication Interface 1


Digital Communication Interface 2


Report Print


Operating Voltage


Power Consumption


Outline Size


Operating Temperature


Protection Level


Weight
