Hopper Weighing System

About Hopper Weighing System

Salient Features : No. of Loadcells: 03 or 04 Nos Junction Box: 01 Nos Indicator: Digital Communication Output: RS485, Ethernet TCP/IP, MODBUS Analog Output: 4-20mA Current output Main Features EMC design with high anti jam for industrial environment 32-bit ARM CPU with 72MHz clock & Higharithmetic speed. 6+10 Green VFD Digit display. 24-bit ADC with internal resolution1/1000000. High sampling frequency 400Hz. Special Anti-vibration digital filtering algorithm for precise weighing stable display and rapid response. Auto zero tracking. Fall value auto correction. Auto pause for deviation alarm. Auto re-feed for negative deviation alarm. 3-speed feeding control by Dos or AOs. Definable AO/COM. Recipe Number 10 Technical Specifications Power Supply: AC80-260V, 50/60Hz Max 10W Loadcell Excitation Voltage/Current: DC10V/250mA. 8 Loadcells [3500] connectable. Weighing Signal Input range: 0-25mA. 7 Normally Open Switch Inputs DI 12 Normally Open Transistor Outputs DO 1 Analog Signal Output AO 4-20mA COM1: RS232; COM2: RS485/RS422/Profius-Dp/Ethernet Connect Host IPC[Modbus] & Remote Display Outline Sie WxHxD : 164 x 82 x 188mm Panel Cutout Size WxH: 153 x 77mm Operating Temperature: -25 C -+45 C Accuracy Grade Ill Verification Accuracy: 0.25% Static Weighing Accuracy: 0.2%-0.5% Packing Accuracy 0.2-0.5% Applications Bagging Machine Loss in Weight Ration Packing Scale Hopper/ Bin Weighing Tank/Silo Weighing Specification Country of Origin Made in India Indicator Digital Brand Esskay Weighing Range up to 200 ton Automation Grade Automatic Display Type Digital Load Cells 3 Nos or 4 Nos Capacity up to 150 Ton Accuracy 0.25% F.S. Rated Load 0-200T
